- Includes a 200W solar suitcase, a 20A waterproof Voyager charge controller, and alligator clips.
- Renogy solar panels using grade A+ monocrystalline solar cells.
- PWM charge controllers ensure charging efficiency and safety.
- Provide flexible for outdoor and off-grid use, easy to carry and set up.
The Renogy 200W solar suitcase is perfect for outdoor adventures, or as a backup power source for your home or cabin. The suitcase gives you dependable power and grid independence for a wide range of applications. This kit includes two 100W Monocrystalline solar panels which can provide up to 1kWh of power each day. Additonally, it includes a Voyager 20A Waterproof Solar Charge Controller, which works with multiple battery types, and a 9 foot alligator clip tray cable, and a protective case for safe and easy transport and storage.
Super Easy to Set up
Renogy 200W Solar Suitcase comes with adjustable aluminum kickstand, making it super easy to set up. This kit includes a 200W solar panel, Voyager 20A PWM Waterproof Charge Controller, and alligator clip tray cables. It can be integrated with your existing system.
Remarkable Outdoor Performance
Renogy solar panels use low iron-tempered glass which is more durable than standard solar panels. High quality protective case and IP 65 rated splashproof and dust proof make it an ideal unit to bring along outdoor adventures, working perfectly fine when exposed to harsh weather.
Outstanding Performance in Low-Light Conditions
Bypass diodes installed inside the junction greatly reduce power loss caused by shading. Meanwhile, it avoids the effects caused by hot spots, ensures excellent performance as well as product safety during use.
Grade A+ Monocrystalline Solar Cells
Unlike other low-grade solar cells, the Renogy 100Watt portable solar panel uses Grade A+ Monocrystalline Solar Cells which passed rigorous EL testing. It will not suffer from hidden cracks or other safety issues, ensuring a high conversion efficiency of up to 22%.
Compatible With Multiple Battery Types
The Voyager controller can automatically sense 12V or 24V system voltage when paired with a Gel, AGM, or Flooded battery. It also comes with a convenient Lithium activation feature.
Multiple Charging Protections
Advanced smart PWM technology charge controllers ensure charging efficiency and safety. The smart, waterproof Voyager 20A charge controller has multiple intelligent protections against reverse polarity, over-charge, short-circuit, and reverse-current, keeping your batteries fully protected 100% of the time!
NOTE
- If you have any questions regarding this product, please call us at 1 (909) 287-7111 or or submit a ticket for troubleshooting assistance.
- More questions about your off-grid power system? Learn more from Renogy Learning Blog!
Package Includes
200 Watt Mono Foldable Solar Suitcase
1 x
|
20A Voyager Charge Controller
1 x
|
Solar Connectors to Alligator Clips w/ Fuse
1 x
|
200 Watt Monocrystalline Foldable Solar Suitcase
Maximum Power at STC:
200W
Open-Circuit Voltage:
24.3V
Short-Circuit Current (Isc):
10.42A
Maximum Operating Voltage (Vmp):
20.4 V
Maximum Operating Current (Imp):
9.82 A
Maximum System Voltage:
600 VDC (UL)
Folded Dimension:
41.81x20.87x2.76 in(1062x530x70mm)
Weight:
34.39lb (15.6kg)
New Edition Voyager 20A PWM Waterproof Solar Charge Controller
Nominal Voltage:
12 /24VDC
Rated Charge Current:
20A
Max. PV Input Voltage:
55 VDC
Grounding:
Common Positive
Power Consumption:
0.24W (12V) / 0.74W (24V)
Operating Temperature:
-31°F - 113°F
Dimensions:
6.08 x 3.83 x 1.40 inches
Weight:
0.55 lbs
Solar Connector to Alligator Clips Adapter
SPECS:
14 AWG Cable, 9.84ft, 15A built in Fuse
opc:
Material and workmanship warranty:
3
Performance Warranty:
5 year 95% output warranty 10 year 90% output warranty 25 year 80% output warranty
ETL Listed [UL-458], CE and RoHS compliant, FCC Class B Part 15 Compliant, Manufactured in a Certified ISO 9001 Facility:
Yes
opc:
FAQ
1. Which kind of extension cord I should purchase with this panel for more mobility from my RV?
The Renogy Solar Panel Extension Cable will be able to make more space between your solar panels and the charge controller. There is multiple size choice, please choose the same size of cable for extension. And please also realize that the longer the extension, the greater the line loss. A bigger gauge will be required for longer runs.
2. Can I add more solar panels with the suitcase to expand my system??
This solar suitcase is designed for expansion, additional panels are added to the system available based on your needs and space. We suggest you add the same solar suitcase for expansion. And please also pay attention to the controller may also need to be upgraded when you extend your system, the kit original comes with a 20A Voyager charge controller, divide the total power by the battery system voltage, the current value get can be used as a reference for controller selection.
3. Are these monocrystallin or polycrystallin panels?
The suitcase with 2 pcs 100W Renogy high quality monocrystalline solar panels.
4. What type of batteries can be used with the kit?
Battery type compatibility depends on the charge controller specified compatible battery type. This solar kit comes with a Renogy Voyager 20A PWM waterproof charge controller. It supports Gel, AGM, Flooded, and Lithium batteries. Still, please set the correct battery type once it is installed and if a Lithium battery is connected, please manually set the system voltage due to the corresponding battery voltage. It also comes with a Lithium activation feature.
5. Can I add more solar panels with the suitcase to expand my system?
Yes, additional panels added to the system are available based on your needs and space. We suggest you add the same solar suitcase for expansion.
6. How much power this solar kit can provide me?
The power produced by solar panels will depend on how much sunlight can get. The ideal output for this kit will be 1kWh every day(Calculated based on 200Wx5h expected sunlight availability).
7. Can I use this suitcase to charging my 120v receptacles directly?
The suitcase is not able to charging 120V power receptacles directly. Plus a 12v battery and inverter would give 120v output you would want. The panel would recharge the battery, the battery will storage the power, and the inverter would be able to supply the 120v power that you need.
8. Why is my solar panel underproducing?
Solar panel performance may be hindered for a number of reasons. Most commonly environmental conditions such as indirect sunlight, temperature rise, cloudy sky, and dirt and stain build up on the top glass will cause a reduced power output. This is a portable suitcase, you may try to move it in place or adjust the kickstands angels to get better sunshine. The ideal output of it will be around 500 Watt-hours per day (Calculated based on 100Wx5h expected sunlight availability).
